The Bently Nevada 9200-06-02-05-00 stands as a cornerstone in the field of industrial condition monitoring. This two-wire velocity seismoprobe transducer measures absolute vibration of bearing housings, casings, or structural elements. By utilizing a self-generating moving-coil design, the 9200 series provides a voltage output proportional to the vibration velocity. Reliability remains the primary focus of this sensor, as it operates without the need for external power, making it a robust choice for critical machinery protection.

Comprehensive Model Configuration

The specific part number 9200-06-02-05-00 indicates a highly specialized configuration designed for versatile industrial use:

• Mounting Angle & Frequency (-06): This option supports a mounting angle of 0 ±100 degrees. It features a minimum operating frequency of 10 Hz (600 cpm), which allows the sensor to capture low-frequency vibrations common in large rotating equipment.
• Connector Option (-02): The side-mount connector design facilitates installation in tight spaces where top-clearance is limited. This configuration does not include a cable, allowing users to select their preferred cabling solution.
• Mounting Base (-05): This version comes without a standard base but includes a 1/2-20 UNF-3A stud. This allows for direct, rigid attachment to the machine surface, ensuring maximum signal integrity.
• Agency Approvals (-00): This is the standard version, suitable for environments where specific hazardous area certifications are not required.

High-Precision Technical Performance

The 9200-06-02-05-00 delivers exceptional sensitivity of 20 mV/mm/s (500 mV/in/s) with a tight ±5% tolerance when properly oriented. Its electromagnetic design ensures that even minor mechanical imbalances or misalignments generate a clear, measurable signal.

Engineers optimized the transducer for a dynamic operating range of up to 2.54 mm (0.100 in) peak-to-peak displacement. With a velocity range of 25 mm/s (1 in/s), the sensor handles the vibration levels typically found in motors, pumps, and fans. The coil resistance sits at 1.25 kΩ, and the locked coil inductance measures 125 mH, providing stable electrical characteristics for long-term deployment.

Rugged Environmental Engineering

Bently Nevada constructs the 9200 series to withstand the rigors of the plant floor. The case utilizes Anodized Aluminum A204, which provides excellent corrosion resistance and physical durability. A Neoprene gasket seals the unit, ensuring it remains resistant to dust and moisture.

The transducer operates reliably in temperatures ranging from -29°C to +121°C (-20°F to +250°F). It also handles relative humidity up to 95% (non-condensing). Weighing only 300 grams (10.5 ounces) and standing approximately 102 mm tall, this compact device fits into diverse machinery layouts without adding significant mass that might alter the vibration characteristics of the machine itself.

Strategic Industrial Applications

The 9200-06-02-05-00 excels in monitoring “mid-range” frequencies where velocity measurements provide the best indication of machine health. Typical applications include:

1. Industrial Fans and Blowers: Detecting imbalance or aerodynamic instability.
2. Centrifugal Pumps: Monitoring for bearing wear or hydraulic issues.
3. Electric Motors: Identifying rotor bars issues or mechanical looseness.
4. Small Turbines: Providing a cost-effective alternative to displacement probes for non-critical casing monitoring.

Because the sensor generates its own signal, it simplifies the wiring architecture. Operators can connect the two-wire output directly to Bently Nevada monitors or other standard data acquisition systems that accept a velocity input.

Key Specifications Table

Product Visual References

The following links provide high-quality visual representations of the Bently Nevada 9200 series for identification purposes:

1. Product Profile: Bently Nevada 9200 Seismoprobe View (Shows the classic cylindrical anodized aluminum body).
2. Connector Detail: Side Mount Connector Configuration (Displays the side-entry electrical connection port).
3. Mounting Interface: 1/2-20 UNF Mounting Stud Illustration (Highlights the base connection for industrial attachment).
