1756-OB8 | Allen-Bradley Digital DC Output Module Supplier
Introduction:
The 1756-OB8 from Allen-Bradley offers eight 24VDC output channels for reliable ControlLogix system control.
Customer Reviews
UBEST Automation – Trusted Global Automation Parts Supplier
We offer a wide range of in-stock industrial automation spare parts. All products come with a 12-month warranty and a 30-day refund for quality issues.
Product Attributes:
Notice: For real-time prices and inventory, please click the button below to contact us.
Introduction to the 1756-OB8
When your ControlLogix system demands precise digital output control, the 1756-OB8 provides a robust solution. This Allen-Bradley module is a Digital DC output module designed for industrial automation. It features eight output channels, making it suitable for energizing DC loads in various applications. As part of the ControlLogix series, it integrates seamlessly into existing setups, offering reliability and ease of service for maintenance engineers.
Key Features and Technical Specs
- Manufacturer: Rockwell Automation, brand: Allen-Bradley.
- Module type: Digital DC output module, series: ControlLogix.
- Number of outputs: eight (8).
- Output voltage: 24VDC, with a range of 10-30VDC.
- Number of output groups: two (2), with four (4) channels per group.
- Current per point: 2 A at 60 °C (140 °F).
- Maximum current per module: 8 A at 60 °C (140 °F).
- Signal delay, ON transition: 1 ms max; OFF transition: 2 ms max.
- Backplane current: 165 mA at 5.1VDC and 2 mA at 24VDC.
- Total backplane power: 0.89 W.
- Removable terminal blocks: 1756-TBNH and 1756-TBSH.
A distinctive spec is the signal delay of only 1 ms for ON transitions and 2 ms for OFF transitions, which ensures rapid response in time-critical processes. This minimizes lag in output activation, enhancing overall system efficiency.
Applications and Use Cases
The 1756-OB8 excels in applications requiring reliable DC output control, such as conveyor systems, packaging machinery, and material handling. For instance, in a bottling plant, this module can control solenoid valves for filling operations, ensuring consistent performance. Its eight-point output configuration allows for flexible load management, reducing the need for multiple modules. Maintenance engineers appreciate its straightforward integration into ControlLogix chassis, simplifying upgrades and troubleshooting.
Installation and Setup
Installing the 1756-OB8 is straightforward. It occupies a single slot in any ControlLogix chassis except the leftmost slot, which is reserved for the processor or communication module. Use the 1756-TBNH or 1756-TBSH removable terminal blocks for wiring. Ensure the module is properly keyed to prevent misconnection. After mounting, configure the module in your control software, setting parameters like Request Packet Interval (RPI) and fault mode states. Always follow the manufacturer's guidelines for safe installation.
Maintenance and Reliability
For long-term reliability, inspect the 1756-OB8 periodically for signs of wear or environmental stress. The module operates in temperatures from 0 to 60 °C and non-condensing humidity of 5% to 95%. Regular checks of terminal block connections can prevent intermittent faults. Given its maximum power dissipation of 2.5 W, ensure adequate airflow around the chassis. Routine maintenance helps avoid unexpected downtime, supporting cost-effective operations.
Compatibility and Integration
The 1756-OB8 is compatible with any ControlLogix chassis and works with standard power supply modules. It can function as local I/O or as part of a distributed I/O system. The module supports communication formats such as rack optimization and output data. For integration, refer to the official Allen-Bradley documentation for detailed configuration steps. This flexibility makes it a versatile choice for expanding control systems.
Troubleshooting and Common Issues
Common issues with the 1756-OB8 include output failures due to loose connections or incorrect configuration. Check the terminal block seating and verify that the module is properly recognized in the chassis. If outputs do not energize, confirm the power supply voltage is within the 10-30VDC range. Use the module's fault mode settings to set outputs to a safe state during errors. For persistent problems, consult the product manual or contact PetroPartsOnline for support.
FAQ about 1756-OB8
Q: What is the output voltage range of the 1756-OB8?
A: The output voltage range is 10-30VDC, with a nominal voltage of 24VDC.
Q: How many output channels does the 1756-OB8 have?
A: It has eight output channels, organized into two groups of four channels each.
Q: What is the maximum current per point for the 1756-OB8?
A: The maximum current per point is 2 A at 60 °C (140 °F).
Q: What removable terminal blocks are compatible with the 1756-OB8?
A: Compatible terminal blocks are the 1756-TBNH and 1756-TBSH.
Q: What is the backplane power consumption of the 1756-OB8?
A: The total backplane power is 0.89 W, with a current draw of 165 mA at 5.1VDC and 2 mA at 24VDC.
Product Support and Availability
The 1756-OB8 is available from PetroPartsOnline, an industrial automation and oil/gas parts supplier. Check current lifecycle status and stock availability before ordering. For technical support, contact our team for assistance with integration and troubleshooting.
