1756-IA16I | Allen-Bradley Digital AC Input Module Supplier
Introduction:
The 1756-IA16I is a 16-point individually isolated AC input module from Allen-Bradley, designed for reliable signal acquisition in ControlLogix systems.
Customer Reviews
UBEST Automation – Trusted Global Automation Parts Supplier
We offer a wide range of in-stock industrial automation spare parts. All products come with a 12-month warranty and a 30-day refund for quality issues.
Product Attributes:
Notice: For real-time prices and inventory, please click the button below to contact us.
What Happens When Your Input Module Lacks Isolation?
In industrial environments, electrical noise and ground loops can corrupt digital signals, leading to false readings and costly downtime. The 1756-IA16I from Allen-Bradley solves this challenge with individually isolated channels, ensuring each input operates independently. This module is part of the ControlLogix series and delivers robust performance for demanding applications.
Key Features & Technical Specs of the 1756-IA16I
- Manufactured by Rockwell Automation under the Allen-Bradley brand.
- Features 16 individually isolated inputs for reliable signal integrity.
- Operates at a nominal input voltage of 120 Volts AC.
- Accepts an operating voltage range of 79-132 Volts AC.
- Programmable input delay time of 9 or 18 milliseconds for flexibility.
- Minimum operating current of 5 milliamperes at 79 Volts AC, 47-63 Hertz.
- Maximum operating current of 15 milliamperes at 132 Volts AC, 47-63 Hertz.
- Off-state current limited to 2.5 milliamperes maximum.
- Power dissipation of 4.9 Watts at 60 degrees Celsius.
- Backplane current draw of 125 milliamperes at 5 Volts and 2 milliamperes at 24 Volts.
- Uses electronic module keying for correct installation.
- Compatible with 1756-TBCH or 1756-TBS6H removable terminal blocks.
- UPC code: 10612598164476.
A standout spec is the 16 individually isolated inputs. Unlike modules with shared commons, each channel here has its own return path, which prevents ground loops and allows mixing of different AC sources without interference. This is critical in applications where signal accuracy is paramount.
Applications & Use Cases for the 1756-IA16I
This module excels in monitoring discrete AC signals from sensors, push buttons, and limit switches. In manufacturing lines, the isolated inputs help maintain signal integrity despite nearby motors or drives. For example, in a packaging plant, the 1756-IA16I can reliably read inputs from multiple zones without cross-talk. Additionally, it suits remote I/O setups where long wiring runs might introduce noise.
Installation & Setup Guide
Mount the 1756-IA16I directly into a ControlLogix local or remote chassis. Ensure the chassis is powered off before insertion. Use the compatible 1756-TBCH or 1756-TBS6H terminal block for wiring. Connect each AC input signal to its respective terminal, observing the voltage range of 79-132 Volts AC. Configure the input delay time via software to 9 or 18 milliseconds based on your application needs. After wiring, power up the chassis and verify module health via the front panel indicators.
Maintenance & Reliability Tips
To maximize uptime, periodically inspect the terminal block connections for tightness and signs of corrosion. Keep the module environment within its rated temperature range to avoid overheating. The 1756-IA16I is designed for long service life, but regular checks of the LED status indicators can help detect issues early. For best results, follow the manufacturer's guidelines for cleaning and handling.
Compatibility & Integration
The 1756-IA16I integrates seamlessly with any ControlLogix processor and communication adapter for remote I/O applications. It uses a 36-pin removable terminal block for easy wiring replacement without rewiring the entire module. The electronic keying feature prevents incorrect module insertion, simplifying setup.
FAQ about 1756-IA16I
Q: What is the input voltage range for the 1756-IA16I?
A: The operating voltage range is 79-132 Volts AC, with a nominal input voltage of 120 Volts AC.
Q: How many inputs does the 1756-IA16I have?
A: It has 16 individually isolated inputs, each with its own common.
Q: What terminal blocks are compatible with the 1756-IA16I?
A: The module works with 1756-TBCH and 1756-TBS6H removable terminal blocks.
Q: Can the input delay be adjusted on the 1756-IA16I?
A: Yes, the input delay time is programmable to either 9 or 18 milliseconds.
Q: What is the maximum power dissipation of the 1756-IA16I?
A: The maximum power dissipation is 4.9 Watts at 60 degrees Celsius.
Product Support & Availability
The 1756-IA16I is in stock and ready to ship from PetroPartsOnline. Contact our team for lifecycle status and availability before ordering. We provide fast delivery for industrial automation and oil/gas parts.
