Schneider BMXNOE0100 Ethernet Module Overview

The Schneider Electric BMXNOE0100 is a TCP/IP Ethernet network module. Specifically, it belongs to the Modicon M340 automation platform family. Therefore, this module adds Ethernet connectivity to M340 systems. Consequently, users select the BMXNOE0100 for transparent industrial networking. Moreover, the concept is Transparent Ready for seamless integration. Finally, the module includes a supplied flash card (BMXRWSC016M) for memory expansion.

Technical Specifications of BMXNOE0100

The Schneider Electric BMXNOE0100 has a product type of TCP/IP Ethernet module. Specifically, the integrated connection uses Ethernet TCP/IP over RJ45. Furthermore, the speed is 10/100 Mbit/s with one twisted pair. Protection processing uses TC for reliable operation. The module complies with Class B30 standards. Ethernet port supports both 10BASE-T and 100BASE-TX.

Communication services include bandwidth management and data editing. Users can access the data editor via a PC terminal. Additionally, an FDR server handles device replacement. Rack viewer provides remote visualization capabilities. SNMP network manager enables standard monitoring tools. Global data exchange and I/O scanning are both supported. Modbus TCP messaging ensures compatibility with many devices. A configurable web server is also available.

The BMXNOE0100 draws power from the internal rack supply. Current consumption is 90 mA at 24 V DC. The net weight is only 0.2 kg for easy mounting. Local signaling includes multiple LED indicators. Specifically, a green LED shows Ethernet activity (ETH ACT). Another green LED indicates processor run status (RUN). A third green LED displays Ethernet network status (ETH STS).

A red LED indicates data rate at 100 Mbit (ETH 100). Another red LED shows memory card errors (CARD ERR). Finally, a red LED indicates processor or system errors (ERR). A RESET button provides cold start control. The module includes a supplied flash card (BMXRWSC016M). Memory usage covers application programming and web server activation.

Environmental and Certification Information

The Schneider Electric BMXNOE0100 operates from 0°C to 60°C. Relative humidity ranges from 10% to 95% non-condensing. IP rating is IP20 for indoor protection. The module complies with Low Voltage Directive 2014/35/EU. Additionally, it meets EMC Directive 2014/30/EU. CE marking confirms European regulatory compliance. This is a standard category module for general use.

Installation Guidelines for Schneider BMXNOE0100

First, insert the BMXNOE0100 into an available M340 rack slot. Then, push firmly until the module locks into place. After that, connect an RJ45 cable to the Ethernet port. Next, apply power to the M340 rack system. Subsequently, observe the LED indicators for proper startup. Finally, configure the IP address using a PC terminal.

First, set the rotary switches for the last two IP octets. Then, use the RESET button for a cold start if needed. After that, access the configurable web server via a browser. Next, enable I/O scanning for remote devices. Do not exceed the operating temperature of 60°C. Finally, secure the Ethernet cable with a strain relief clip.

Package Contents of BMXNOE0100

Your shipment includes these items:

One Schneider Electric BMXNOE0100 Ethernet module

One BMXRWSC016M flash card (supplied)

One product documentation leaflet

However, the package does not include the M340 rack. Therefore, you must purchase the rack separately. Also, no RJ45 cable is provided with this module. Finally, configuration software is not included in the shipment.

Frequently Asked Questions about BMXNOE0100

1. What communication services does the BMXNOE0100 support?

The Schneider BMXNOE0100 supports bandwidth management and I/O scanning. Specifically, it also handles Modbus TCP messaging and global data. Additionally, an FDR server and SNMP network manager are included. Therefore, this module integrates with most industrial networks.

2. Can I access the BMXNOE0100 through a web browser?

Yes, the BMXNOE0100 includes a configurable web server. Specifically, you can monitor and control the module via a standard browser. Therefore, no special software is needed for basic diagnostics. Use the IP address in your browser for access.

3. What is the power consumption of this Ethernet module?

The Schneider BMXNOE0100 consumes 90 mA at 24 V DC. Specifically, it draws power from the internal rack supply. Therefore, no external power connection is required. The total load depends on other modules in the rack.

4. What do the red LEDs indicate on the BMXNOE0100?

The BMXNOE0100 has three red LEDs for different conditions. Specifically, ETH 100 lights when operating at 100 Mbit speed. CARD ERR lights for memory card problems. ERR lights for processor or system errors. Therefore, check the manual for detailed troubleshooting.

5. Is the BMXNOE0100 suitable for outdoor installations?

No, the Schneider BMXNOE0100 has an IP20 rating only. Specifically, this is for indoor control cabinet use only. Therefore, protect the module from dust and moisture. For outdoor use, install it inside a weatherproof enclosure.

Compatibility and Application Notes

The Schneider Electric BMXNOE0100 works exclusively with Modicon M340 platforms. Specifically, it mounts into any standard M340 rack slot. Use this module for Ethernet connectivity in automation systems. The supplied BMXRWSC016M flash card stores application programs. HS code for customs is 85176200. Finally, store the module in anti-static packaging before installation. This product complies with EU Low Voltage and EMC directives.
