ABB CI522A AF100 Interface Module 3BSE018283R1 Redundant Comm
Introduction:
The ABB CI522A is an AF100 Interface Module for redundant communications. It connects the S800 I/O system to the Advant Master process control system. The ABB CI522A carries part number 3BSE018283R1.
Customer Reviews
UBEST Automation – Trusted Global Automation Parts Supplier
We offer a wide range of in-stock industrial automation spare parts. All products come with a 12-month warranty and a 30-day refund for quality issues.
Product Attributes:
Notice: For real-time prices and inventory, please click the button below to contact us.
Product Overview
The ABB CI522A belongs to the Advant Master family. This module provides a dedicated AF100 interface to S800 I/O. The ABB CI522A enables redundant communication paths for high availability. You can use this module in critical process control applications. The design supports reliable data exchange between controllers and field I/O. The ABB CI522A helps build fault-tolerant automation architectures.
Technical Specifications
The ABB CI522A delivers robust communication performance for Advant Master systems. All parameters follow the official datasheet.
Communication Capabilities
Product type: Communication Module
Interface type: AF100 interface
Connected system: S800 I/O system
Communication mode: Redundant communications support
System compatibility: ABB Advant Master Process Control System
Physical Dimensions
Product net depth: 265 mm
Product net height: 27 mm
Product net width: 120 mm
Product net weight: 0.2 kg
The ABB CI522A has a slim 27 mm profile for panel mounting.
Environmental Compliance
RoHS information: Exempted from 2011/65/EU (RoHS)
Exemption article: 2(4)(c), (e), (f) and (j) as provided
Declaration reference: 3BSE088609 EU DECLARATION OF CONFORMITY
WEEE category: 5 (Small Equipment, no external dimension more than 50 cm)
Number of batteries: 0
SCIP number: 91d693ab-f84a-4bd4-b01c-c2d1f60d1262 (Sweden)
Ordering Information
Exchange part number: EXC3BSE018283R1
HS Code: 85176200
Customs tariff number: 85176200
Installation Guide
Follow these steps to install the ABB CI522A correctly.
Power down your Advant Master chassis before inserting the module.
Align the ABB CI522A with the correct slot in the rack.
Slide the module firmly into place until fully seated.
Secure the module using the retaining screws at top and bottom.
Connect the AF100 cable to the S800 I/O system.
Configure redundant paths in your Advant Master software.
Apply power and verify communication status.
Packing List
This package for the ABB CI522A includes the following items.
ABB CI522A AF100 Interface Module (one unit)
Product identification label sheet
Anti-static protective bag
Basic installation instructions leaflet
Frequently Asked Questions (FAQ)
1. What system does the CI522A interface with?
The ABB CI522A interfaces with S800 I/O systems. It connects them to the ABB Advant Master Process Control System via AF100 protocol.
2. Does the ABB CI522A support redundant communication?
Yes, the ABB CI522A supports redundant communications. This feature provides high availability for critical process applications.
3. Is the CI522A RoHS compliant?
The ABB CI522A is exempted from RoHS 2011/65/EU. The exemption follows Article 2(4)(c), (e), (f) and (j). See declaration 3BSE088609 for details.
4. What is the exchange part number for the ABB CI522A?
The exchange part number is EXC3BSE018283R1. Use this number when ordering a replacement ABB CI522A module.
5. What are the dimensions of the CI522A module?
The ABB CI522A measures 265 mm deep, 27 mm high, and 120 mm wide. It weighs only 0.2 kg for easy installation.
