Product Overview

The 1792D-16BVT0D is a 16-point digital output module from the Allen-Bradley ArmorBlock series. It provides robust output control in a compact, IP67-rated package. This module is designed for direct on-machine mounting in harsh industrial environments. It eliminates the need for an external enclosure. The module uses a standard DeviceNet communication interface. It delivers reliable switching of DC loads. Each output channel is individually protected. The module supports both sourcing and sinking configurations. It is ideal for distributed control architectures. The unit reduces wiring and installation costs. It simplifies system design and maintenance. The module is a genuine Allen-Bradley product. It is available as a new original unit. The unit is currently in stock for immediate shipment. It comes with a 12-month warranty. The product is manufactured in the United States. It is a key component for modern automation systems.

Application Scenarios

The 1792D-16BVT0D is used in material handling systems. It controls conveyor belts and diverters. It is common in automotive assembly lines. The module manages pneumatic valves and actuators. It is applied in packaging machinery. The unit operates in food and beverage processing. It is suitable for heavy industrial environments. The module is used in warehouse automation. It controls robotic tool changers. It is ideal for water treatment facilities. The unit is deployed in oil and gas applications. It works in textile manufacturing lines. The module is used in pharmaceutical production. It is effective in woodworking and metalworking. The unit supports remote I/O applications. It is a standard choice for distributed control. The module is used in both new installations and retrofits. It is compatible with various PLC and control systems. The unit is a reliable solution for on-machine control.

Technical Specifications

The module features 16 digital output points. It operates on 24V DC input power. The output type is sourcing or sinking. It supports up to 2 amps per output. The total current per module is 8 amps. The module uses a DeviceNet interface. It supports baud rates of 125, 250, and 500 kbps. The unit has a 5-pin micro-style connector. It includes a 5-pin power connector. The module has an IP67 environmental rating. It operates in temperatures from -20 to 60 degrees Celsius. The unit measures approximately 4.5 inches in height. It is 2.5 inches wide and 1.5 inches deep. The module weighs about 0.5 kilograms. It has built-in short circuit protection. It includes reverse polarity protection. The unit has LED indicators for power and status. It supports Group 2 only DeviceNet behavior. The module is fully RoHS compliant. It meets CE and CULus standards.

Installation & Maintenance Guide

Mount the module directly on a flat surface. Use the provided mounting holes. Connect the DeviceNet cable to the 5-pin connector. Wire the output devices to the terminal block. Apply power to the module. Set the node address using the rotary switches. Configure the baud rate using the dip switches. Verify the LED indicators for proper operation. Perform a functional test of all outputs. Regularly inspect the module for damage. Clean the unit with a dry cloth. Check all connections for tightness. Replace the module if it shows signs of wear. Do not open the module casing. Use only approved replacement parts. Follow all local electrical codes. Ensure the module is properly grounded. Store the unit in a dry, clean environment. Avoid exposure to extreme temperatures. Use the module only within its rated specifications.

Frequently Asked Questions (FAQ)

What is the primary function of 1792D-16BVT0D?

This module provides 16 digital output points to control DC loads such as solenoids, valves, and indicators in an industrial automation system.

What is the environmental rating of this module?

The unit has an IP67 rating, meaning it is dust-tight and protected against temporary immersion in water, suitable for wash-down environments.

Which communication protocol does the module use?

It uses the DeviceNet communication protocol, a common industrial network for connecting sensors and actuators to a controller.

Can the module be mounted directly on a machine?

Yes, its IP67 rating and compact design allow for direct on-machine mounting without an additional enclosure in most industrial environments.

What is the maximum current per output channel?

Each output channel can handle up to 2 amps, with a total module current limit of 8 amps across all 16 channels.
