Product Overview

The 1792D-16BVT0CD is a compact I/O module from the Allen-Bradley ArmorBlock series. It provides reliable digital input and output functions for distributed control systems. This module is designed for rugged industrial environments. It offers 16 channels for versatile signal handling. Each channel supports both input and output operations. The module uses a standard backplane connector for easy installation. Its compact form factor saves valuable cabinet space. The 1792D-16BVT0CD is a new original unit in stock. It is ideal for applications requiring local I/O processing.

Application Scenarios

This module is commonly used in automated assembly lines. It can control sensors and actuators directly. The 1792D-16BVT0CD works well in material handling systems. It is also suitable for packaging machinery. The module supports conveyor control applications. It can manage simple on/off devices like valves and motors. The module is often deployed in water treatment facilities. It is also used in food and beverage processing equipment. The module can operate in standard industrial warehouse storage. It handles temperatures from 0 to 60 degrees Celsius.

Technical Specifications

General

• Product Type: ArmorBlock I/O Module
• Number of Channels: 16
• Input Voltage Range: 10-30 VDC
• Output Current: 0.5 A per channel
• Operating Temperature: 0 to 60 °C
• Storage Temperature: -40 to 85 °C
• Humidity: 5 to 95% non-condensing
• Protection Rating: IP20

Communication

• Backplane Interface: DeviceNet compatible
• Power Supply: 24 VDC nominal
• Power Consumption: 2.5 W typical

Physical

• Dimensions: 120 x 80 x 40 mm
• Weight: 0.2 kg
• Mounting: DIN rail
• Connector: 16-point terminal block

Installation & Maintenance Guide

Mount the module on a standard DIN rail. Ensure the power supply is disconnected before wiring. Connect the backplane cable to the module port. Wire field devices to the terminal block channels. Use shielded cable for long runs to reduce noise. Secure the module with the locking latch. Do not exceed the rated voltage or current. Periodically inspect connections for signs of wear. Keep the module clean and free of debris. Follow standard ESD precautions during handling.

Frequently Asked Questions (FAQ)

What is the primary function of 1792D-16BVT0CD?

The module provides 16 digital I/O channels for local control. It is part of the ArmorBlock series from Allen-Bradley. It connects to a DeviceNet backplane for data exchange.

What is the operating voltage for this module?

The module operates on a nominal 24 VDC supply. The input voltage range is 10 to 30 VDC. Always verify the supply voltage before connection.

Can this module be used in outdoor environments?

The module has an IP20 protection rating. It is not designed for outdoor use. Install it inside a suitable enclosure for protection.

What is the maximum cable length for field wiring?

Standard industrial practice recommends cable lengths under 30 meters. Use shielded twisted-pair cable for best performance. Longer runs may require signal conditioning.

Is this module compatible with other ArmorBlock modules?

Yes, the module is fully compatible with the ArmorBlock series. It can be mixed with other I/O modules on the same backplane. Check the system manual for power budget limits.
