1790D-T16BV0 | Allen-Bradley CompactBlock I/O Module
Introduction:
CompactBlock LD I/O module with 16 digital points, DeviceNet communication, and integrated power supply. New original unit, 12-month warranty.
Customer Reviews
UBEST Automation – Trusted Global Automation Parts Supplier
We offer a wide range of in-stock industrial automation spare parts. All products come with a 12-month warranty and a 30-day refund for quality issues.
Product Attributes:
Notice: For real-time prices and inventory, please click the button below to contact us.
Product Overview
The 1790D-T16BV0 is a CompactBlock LD I/O module from Allen-Bradley. It provides 16 digital input and output points in a compact form factor. This module is designed for distributed control applications where space is limited.
It supports 24V DC operation and includes a built-in power supply. The module communicates via DeviceNet, simplifying wiring and reducing installation costs. The 1790D-T16BV0 is ideal for remote I/O applications in industrial automation.
This module is a new original unit, ready for immediate shipment. It includes a 12-month warranty and comes from a trusted brand in industrial controls.
Application Scenarios
The 1790D-T16BV0 is used in manufacturing lines, packaging machines, and material handling systems. It connects sensors and actuators to a central controller over a DeviceNet network.
Common applications include conveyor control, pick-and-place stations, and assembly machines. The module operates reliably in harsh industrial environments with temperatures from 0 to 60 degrees Celsius.
It is suitable for both new installations and retrofits of existing systems. The compact size allows mounting directly on machines or in small cabinets.
Technical Specifications
- Product type: CompactBlock LD I/O module
- Input/output count: 16 points (8 inputs, 8 outputs)
- Input voltage: 24V DC, sink/source
- Output voltage: 24V DC, 0.5A per point
- Communication: DeviceNet
- Power supply: 24V DC, integrated
- Operating temperature: 0 to 60 degrees Celsius
- Storage temperature: -40 to 85 degrees Celsius
- Humidity: 5 to 95% non-condensing
- Dimensions: 120 x 80 x 50 mm
- Weight: 0.3 kg
Installation & Maintenance Guide
Mount the module on a standard DIN rail. Ensure adequate clearance for ventilation. Connect the DeviceNet cable to the open-style connector.
Wire field devices to the removable terminal blocks. Use copper wire rated for 75 degrees Celsius. Torque terminals to 0.5 Nm.
Set the node address and baud rate via the rotary switches on the front panel. Power up the module and verify communication with the master scanner.
Periodically inspect for loose connections and contamination. Keep the module clean and dry. Replace only with an identical module from Allen-Bradley.
Frequently Asked Questions (FAQ)
What is the primary function of 1790D-T16BV0?
This module provides 16 digital I/O points for remote control in a DeviceNet network. It connects sensors and actuators to a PLC or controller.
What type of cable is required for DeviceNet communication?
Use a standard DeviceNet trunk cable with a drain wire. The cable must be terminated with 120 ohm resistors at each end.
Can the 1790D-T16BV0 be used with other brands of PLC?
Yes, as long as the master scanner supports DeviceNet protocol. The module operates as a generic DeviceNet slave.
What is the maximum cable length for DeviceNet?
The maximum trunk length depends on the baud rate. At 125 kbps, the maximum length is 500 meters. At 500 kbps, it is 100 meters.
Does the module require an external power supply?
No, the module includes an integrated 24V DC power supply. It draws power directly from the DeviceNet network.
