1763-L16AWA | Allen-Bradley MicroLogix 1100 PLC
Introduction:
Allen-Bradley MicroLogix 1100 PLC with 16 I/O points, 120V AC, Ethernet, LCD display. Compact and reliable for small automation.
Customer Reviews
UBEST Automation – Trusted Global Automation Parts Supplier
We offer a wide range of in-stock industrial automation spare parts. All products come with a 12-month warranty and a 30-day refund for quality issues.
Product Attributes:
Notice: For real-time prices and inventory, please click the button below to contact us.
Product Overview
The 1763-L16AWA is a programmable logic controller from the MicroLogix 1100 series by Allen-Bradley. This compact controller integrates a power supply, processor, and I/O in one unit. It supports 16 digital input and output points. The device operates on 120V AC input power. It includes an LCD display for status monitoring. The controller is designed for small to medium automation tasks. It offers reliable performance in industrial environments. The 1763-L16AWA supports Ethernet communication for networking. It is a cost-effective solution for simple control systems. This controller is ideal for standalone machine control.
Application Scenarios
The 1763-L16AWA is used in various industrial automation applications. It controls conveyors, packaging machines, and material handling systems. The controller manages simple process control tasks. It is suitable for HVAC systems and building automation. The device operates in water treatment facilities. It controls lighting and small assembly lines. The 1763-L16AWA is common in food and beverage processing. It manages pump and fan control systems. The controller is used in agricultural automation. It supports remote monitoring via Ethernet.
Technical Specifications
- Input voltage: 120V AC
- Digital inputs: 10 (24V DC)
- Digital outputs: 6 (relay)
- Program memory: 4K words
- Data memory: 2K words
- Ethernet port: 1 (10/100 Mbps)
- Serial port: 1 (RS-232/485)
- LCD display: 2-line, backlit
- Operating temperature: 0 to 55 °C
- Storage temperature: -20 to 85 °C
- Humidity: 5 to 95% non-condensing
- Dimensions: 120 x 80 x 70 mm
- Weight: 0.5 kg
Installation & Maintenance Guide
Mount the controller on a DIN rail. Ensure proper clearance for ventilation. Connect the AC power supply to the input terminals. Wire digital inputs according to the manual. Connect relay outputs to the load. Use shielded cable for Ethernet connections. Configure the controller using RSLogix 500 software. Download the program via Ethernet or serial port. Verify I/O operation with the LCD display. Perform regular inspection for loose connections. Keep the controller free from dust and moisture. Replace the unit if the LCD shows errors.
Frequently Asked Questions (FAQ)
What is the primary function of 1763-L16AWA?
The 1763-L16AWA is a compact programmable logic controller. It executes user-defined logic to control industrial equipment.
What is the operating voltage for 1763-L16AWA?
The controller requires 120V AC input power. It is designed for standard industrial AC supply.
Does 1763-L16AWA support Ethernet communication?
Yes, the controller includes one Ethernet port. It supports 10/100 Mbps for programming and networking.
What software is used to program 1763-L16AWA?
RSLogix 500 software is used for programming. It supports ladder logic and structured text.
What is the memory capacity of 1763-L16AWA?
The controller has 4K words of program memory. It also includes 2K words of data memory.
