1756-OB16D | Allen-Bradley Diagnostic DC Output Module Supplier
Introduction:
The 1756-OB16D from Allen-Bradley is a 16-point diagnostic DC output module for ControlLogix systems, offering precise point-level diagnostics and reliable performance.
Customer Reviews
UBEST Automation – Trusted Global Automation Parts Supplier
We offer a wide range of in-stock industrial automation spare parts. All products come with a 12-month warranty and a 30-day refund for quality issues.
Product Attributes:
Notice: For real-time prices and inventory, please click the button below to contact us.
Introduction to the 1756-OB16D
When your ControlLogix system demands reliable output control with diagnostic feedback, the 1756-OB16D delivers. This Allen-Bradley module provides 16 diagnostic outputs, each electronically fused, to help you quickly identify and respond to faults. As part of the ControlLogix series, it integrates seamlessly into your existing automation architecture.
With an operating voltage range of 19.2-30 Volts DC and a 24 Volts DC source voltage category, the 1756-OB16D is built for industrial environments where uptime matters. Its diagnostic capabilities—including no-load detection and output verify detection—give you visibility into each output point, reducing troubleshooting time.
Key Features & Technical Specs of the 1756-OB16D
- 16 diagnostic outputs with 8 points per group for flexible wiring.
- Operating voltage range: 19.2-30 Volts DC.
- Maximum output current per point: 2 Amps.
- Maximum module current: 8 Amps at 30 degrees Celsius, 4 Amps at 60 degrees Celsius.
- Power dissipation: 3.3 Watts at 60 Celsius.
- Backplane current: 250 milliamps at 5 Volts, 140 milliamps at 24 Volts.
- Isolation voltage: 50 Volts continuous.
- Requires removable terminal block: 1756-TBCH or 1756-TBS6H.
A standout spec is the per-point electronic fusing combined with diagnostic latching. This means if a point experiences a short circuit, the module can isolate that point and latch the fault, allowing the rest of the system to continue operation. This reduces unplanned downtime and speeds up maintenance.
Applications & Use Cases
The 1756-OB16D is ideal for applications requiring high availability and fast fault detection. In manufacturing lines, its diagnostic outputs can monitor valve or actuator status, alerting operators to failures immediately. For material handling systems, the per-point fusing protects against wiring faults without shutting down the entire zone. Its 16-point density suits medium-scale control tasks where space in the chassis is limited.
Installation & Setup
Install the 1756-OB16D in any available slot of a compatible ControlLogix chassis. You must use a 36-position removable terminal block housing (RTB), either the 1756-TBCH or 1756-TBS6H. Before installing, ensure the chassis and power supply are properly grounded. The module supports user-configurable fault states per point, including Off, On, or Hold Last State, which you can set via the configuration software.
Maintenance & Reliability
Regular inspection of the module and its connections helps maintain reliability. Check for loose wiring or signs of overheating, especially near the terminal block. The diagnostic features, such as no-load detection and output verify, allow you to monitor output health without manual checks. Following the manufacturer's guidelines for periodic testing ensures long service life.
Compatibility & Integration
The 1756-OB16D is designed for the ControlLogix platform and works with compatible ControlLogix chassis and power supplies. It integrates with Rockwell Automation's programming environment for configuration and diagnostics. For wiring, use the specified removable terminal blocks: 1756-TBCH or 1756-TBS6H.
Troubleshooting & Common Issues
If an output fails to turn on, check the point's diagnostic status via the software. The module's short trip diagnostic function (8 A for 180 ms minimum, 10 A for 120 ms minimum) can help identify overloads. For no-load detection issues, verify the load current is above the minimum 3 mA per point. If the module enters fault mode, review the configured fault state per point and ensure the backplane power is within limits.
FAQ about the 1756-OB16D
Q: What is the operating voltage range of the 1756-OB16D?
A: The operating voltage range is 19.2-30 Volts DC.
Q: How many outputs does the 1756-OB16D have?
A: It has 16 diagnostic outputs.
Q: What removable terminal blocks are compatible with the 1756-OB16D?
A: The module works with the 1756-TBCH and 1756-TBS6H terminal blocks.
Q: What is the maximum output current per point?
A: The maximum output current per point is 2 Amps.
Q: Does the 1756-OB16D support diagnostic latching?
A: Yes, it supports diagnostic latching for fault conditions.
Q: What is the isolation voltage of the 1756-OB16D?
A: The isolation voltage is 50 Volts continuous.
Product Support & Availability
The 1756-OB16D is available from PetroPartsOnline. In stock and ready to ship, this module can be ordered directly. For lifecycle status or additional technical details, contact PetroPartsOnline before ordering.
