171CCC76010 | Schneider 32 MHz Modbus Processor Adapter
Introduction:
The 171CCC76010 from Schneider Electric is a Modicon Momentum M1/M1E processor adapter with 32 MHz clock, Modbus protocol, and 512 KB memory.
Customer Reviews
UBEST Automation – Trusted Global Automation Parts Supplier
We offer a wide range of in-stock industrial automation spare parts. All products come with a 12-month warranty and a 30-day refund for quality issues.
Product Attributes:
Notice: For real-time prices and inventory, please click the button below to contact us.
Introduction to the 171CCC76010 Processor Adapter
When your control system demands reliable processing in harsh environments, the 171CCC76010 from Schneider Electric delivers. Part of the Modicon Momentum family, this M1/M1E processor adapter is engineered for real-time applications where every millisecond counts.
With a 32 MHz clock frequency and the ability to execute 1,000 instructions in just 1 ms, this module ensures your processes run smoothly. Whether you are upgrading an existing line or building a new one, the 171CCC76010 provides the performance and flexibility you need.
Key Features and Technical Specifications
The 171CCC76010 is packed with features that make it a versatile choice for industrial automation. Here are the core specs you can rely on:
- Rated supply voltage: 5 VDC ±5%
- Clock frequency: 32 MHz
- Program memory: 18 kB (LL984) or 240 kB (IEC)
- Data memory: 24 kB
- Total memory: 512 KB flash and 512 KB RAM
- Word length: 16 bits
- Discrete I/O processor capacity: 8192 I / 8192 O
- Register I/O processor capacity: 26048 I / 26048 O
- Communication ports: 1 non-isolated RS-232C, 1 I/O bus port
- Ambient operating temperature: 0 to 60°C (non-condensing)
One standout feature is its memory architecture. With 512 KB of flash and RAM, the 171CCC76010 can handle complex programs and large data sets, making it suitable for demanding applications. The 16-bit word length ensures compatibility with standard data handling.
Applications and Use Cases
The 171CCC76010 is ideal for a range of industrial applications, from manufacturing to oil and gas. Its robust design and Modbus communication protocol make it a reliable choice for remote monitoring and control.
For example, in a pipeline monitoring system, the module can process sensor data and execute control logic with minimal latency. Additionally, its wide operating temperature range (-40 to 85°C storage) ensures it can withstand extreme conditions, reducing the risk of failure in the field.
Installation and Setup
Installing the 171CCC76010 is straightforward. The module is powered by the Momentum I/O base, so no separate power supply is needed. Simply mount the adapter onto the base and connect the communication cables.
Ensure the ambient temperature stays within 0 to 60°C during operation to avoid overheating. For optimal performance, follow the guidelines in the Schneider Electric user manual, and verify that all connections are secure before powering up.
Maintenance and Reliability
To keep the 171CCC76010 running reliably, perform regular inspections. Check for dust accumulation on the module and ensure proper ventilation around the enclosure. Since the module is rated for shock resistance up to 15 gn and vibration resistance of 0.75 mm, it is built to withstand typical industrial conditions.
Periodically verify that the firmware and software (e.g., Concept V2.6, Modsoft ≥ V2.5) are up to date to maintain compatibility with your system. If any issues arise, consult the troubleshooting section of the manual.
Compatibility and Integration
The 171CCC76010 communicates via Modbus protocol, making it easy to integrate with a wide range of PLCs and SCADA systems. It supports one non-isolated RS-232C port and one I/O bus port, allowing flexible connectivity.
It is compatible with Concept V2.6, Modsoft ≥ V2.5, ProWORX NxT V2.0, and ProWORX 32 software. This ensures seamless programming and configuration in existing Momentum-based systems.
Troubleshooting Common Issues
If the module fails to communicate, check the RS-232C connection and ensure the baud rate matches your device. For I/O bus issues, verify that the bus terminator is properly installed.
If the processor does not start, confirm that the supply voltage is within 5 VDC ±5% and that the base provides adequate power. For persistent problems, contact PetroPartsOnline for technical support.
FAQ about 171CCC76010
Q: What is the clock frequency of the 171CCC76010?
A: The 171CCC76010 operates at a clock frequency of 32 MHz.
Q: What communication protocols does the 171CCC76010 support?
A: It supports the Modbus protocol via one non-isolated RS-232C port and one I/O bus port.
Q: What is the program memory capacity of the 171CCC76010?
A: It offers 18 kB (LL984) or 240 kB (IEC) of program memory.
Q: What is the operating temperature range for the 171CCC76010?
A: The ambient operating temperature is 0 to 60°C in a non-condensing environment.
Q: How fast does the 171CCC76010 execute instructions?
A: It executes 1,000 instructions in exactly 1 millisecond.
Product Support and Availability
The 171CCC76010 is available at PetroPartsOnline. Contact our team for current stock and lead times. We are here to help you find the right automation components for your needs.
