The AAR145-S00 is a high-density input module from Yokogawa. This unit provides sixteen isolated channels for RTD and POT signals. It supports JIS Pt100 and 0 to 10 kΩ resistance inputs. You can select the input type individually for each channel. This flexibility makes it perfect for complex process control systems. The module ensures reliable data acquisition in demanding industrial environments.

Expert Technical Evaluation & Performance Review

Precision and Accuracy for Critical Measurements

The AAR145-S00 delivers industry-leading accuracy for temperature sensing. For RTD inputs, it achieves an accuracy of ±150 mΩ. For POT inputs, the accuracy is ±0.2% of full scale. This precision ensures your process data is consistently reliable. The module uses a 1 mA measurement current for RTDs. This low current minimizes self-heating effects in the sensor. Your temperature readings will stay accurate over long periods.

The module features a data update period of just 1 second. This allows for near real-time monitoring of your process variables. The input impedance is 1 MΩ or larger when powered on. This high impedance prevents signal loading on your sensors. The allowable input voltage is ±5 V, providing a wide dynamic range.

Robust Isolation and Environmental Stability

Electrical isolation is a key feature of the AAR145-S00. The module provides 500 V AC isolation between input and system. For a single card configuration, this rating increases to 1500 V AC. Between input channels, the isolation is 200 V AC. This robust isolation protects your system from ground loops and surges. It also prevents crosstalk between different measurement channels.

The module handles temperature drift exceptionally well. For RTD inputs, the drift is only ±0.3 Ω per 10 °C. For POT inputs, the drift is ±0.4% per 10 °C. This stability ensures accurate readings even in thermally unstable environments. The burn-out detection function adds another layer of reliability. You can enable or disable this feature for all channels together. The detection time is 60 seconds, allowing for quick fault identification.

Connectivity and Configuration Details

The AAR145-S00 requires specific external components for operation. You must use the dedicated KS8 or AKB335 cable for connections. Compatible terminal boards include the MRT, TERT, and AER4D models. This standardized connectivity simplifies installation and maintenance. The module supports both 3-wire RTD and 2-wire POT configurations.

The total allowable resistance for signal source and wiring is 150 Ω. This limit applies to the wiring resistance per wire. The module consumes a maximum current of 350 mA at 5 V DC. Its total weight is only 0.3 kg, making it easy to handle. The suffix codes indicate a standard type with no explosion protection. This is the basic version of the AAR145 series.

Installation and Wiring Best Practices

Proper wiring is critical for achieving specified accuracy. Ensure all RTD connections use a 3-wire configuration. This compensates for lead wire resistance automatically. Keep the total wiring resistance below 150 Ω per wire. Use shielded twisted-pair cables for all signal connections. This reduces electromagnetic interference from nearby equipment.

Mount the module in a clean, dry environment. Avoid areas with excessive vibration or temperature extremes. Secure the module firmly to the DIN rail or panel. Connect the dedicated cable to the module’s external connector. Then attach the cable to the appropriate terminal board. Verify all connections are tight before applying power.

Maintenance and Longevity Protocols

Regular inspection of the AAR145-S00 ensures long service life. Check all cable connections for signs of corrosion or looseness. Verify the module’s power supply is within the specified range. Monitor the ambient temperature to prevent drift issues. Clean the module’s surface with a dry, lint-free cloth only.

The burn-out detection feature helps identify sensor failures quickly. Set this function to “available” for critical measurement points. The 60-second detection time provides a good balance between speed and noise immunity. If a burn-out alarm triggers, check the sensor and wiring immediately. Replace any faulty components before restarting the system.
