Evaluating the BMXRWSC016M for Your Automation Needs

When selecting a memory card for your Modicon M340 automation platform, the BMXRWSC016M offers a specific set of capabilities. This buyer's guide helps you assess whether this SD flash memory card meets your application requirements, focusing on its compatibility and storage capacity.

Understanding the BMXRWSC016M's Role

The BMXRWSC016M is an SD flash memory card designed for the Modicon M340 automation platform from Schneider. It provides 16 MB of memory capacity and is specifically intended for use with network modules BMXNOE0100 and BMXNOE0110.

As a Transparent Ready class C30 device, it supports web server functionality, enabling remote monitoring and configuration. This makes it a suitable choice for applications requiring data logging or firmware storage for network communication.

Key Specifications and Compatibility

The BMXRWSC016M has a memory capacity of 16 MB, which is sufficient for storing configuration files, web pages, and firmware updates for compatible network modules. Its net weight is 0.004 lb(US) (0.002 kg), and it comes in a package with dimensions of 0.31 in (0.800 cm) height, 4.88 in (12.400 cm) width, and 5.71 in (14.500 cm) length.

Compatibility is limited to the BMXNOE0100 and BMXNOE0110 network modules within the Modicon M340 platform. Ensure your system includes one of these modules before purchasing this memory card.

Applications in Industrial Networking

In a typical manufacturing environment, the BMXRWSC016M can be used to store web server content for the BMXNOE0100 module, allowing operators to access machine status via a standard web browser. This is particularly useful for remote monitoring in oil and gas facilities where centralized control is essential.

Another application involves storing firmware updates for the network module, simplifying maintenance procedures. By keeping the firmware file on the memory card, engineers can quickly update the module without needing a direct connection to a programming tool.

Customer Case Scenario: Streamlining Firmware Updates

Consider a scenario where a plant engineer needs to update the firmware on multiple BMXNOE0100 modules across a facility. By pre-loading the firmware onto a BMXRWSC016M memory card, the engineer can insert the card into each module sequentially, reducing update time and minimizing the risk of errors.

Frequently Asked Questions

What is the memory capacity of the BMXRWSC016M?

The BMXRWSC016M has a memory capacity of 16 MB, as specified in the product data. This is sufficient for storing web server content and firmware files for compatible network modules.

Which network modules are compatible with the BMXRWSC016M?

The BMXRWSC016M is compatible with the BMXNOE0100 and BMXNOE0110 network modules from the Modicon M340 platform. It is not designed for use with other modules or platforms.

Can the BMXRWSC016M be used for data logging?

While the BMXRWSC016M is primarily intended for web server and firmware storage, its 16 MB capacity can support data logging applications if the network module is configured accordingly. For specific data logging requirements, please refer to official Schneider documentation or contact PetroPartsOnline.

Supply Assurance from PetroPartsOnline

PetroPartsOnline offers the Schneider BMXRWSC016M memory card with reliable supply chain support. As a trusted supplier for industrial automation and oil/gas parts, we ensure genuine products and timely delivery. Please verify current lifecycle status and availability with PetroPartsOnline before ordering.
