Bently Nevada 200151-40-02-10 Accelerometer Standard Cable

Product Overview

The 200151-40-02-10 is a high-quality accelerometer interface cable from Bently Nevada. This standard cable features connectors on both ends for easy installation. The 200151-40-02-10 measures exactly 4.0 meters in total length. Engineers use this cable to connect accelerometers to monitoring systems. Therefore, this cable plays a critical role in vibration measurement applications. Additionally, the 200151-40-02-10 works with various Bently Nevada transducers. Its robust construction ensures reliable signal transmission in industrial environments.

Cable Configuration and Options

The model number 200151-40-02-10 breaks down into specific ordering options. First, the base model 200151 represents an accelerometer interface standard cable. Second, the -40 option specifies a cable length of 4.0 meters. Third, the -02 option indicates a blue cable without any armor protection. Finally, the -10 option provides enhanced coupling nuts on both ends. Consequently, these coupling nuts offer a better grip for tightening. You can secure the 200151-40-02-10 firmly to both the accelerometer and the mating connector.

Technical Specifications

Manufacturer: Bently Nevada.
Model: 200151-40-02-10.
Cable Type: Accelerometer interface standard cable.
Connector Configuration: Connectors on both ends.
Length: 4.0 meters (40 decimeters).
Armor Option: Blue cable without armor (-02).
Coupling Nut Type: Enhanced coupling nut (-10).
Coupling Nut Material: Nickel-plated.

Minimum Bend Radius: 63.5 mm (2.5 inches).
Conductor Count: 4 conductors.
Conductor Gauge: 22 AWG.
Shielding: Braided shield with drain wire.
Shield Coverage: 85% coverage minimum.
Outer Jacket Material: PVC.
Connector Molding: Molded directly to the cable.
IP Rating: IP67 seal to transducers.

Temperature Ratings and Environmental Tolerance

The 200151-40-02-10 operates reliably across a wide temperature range. Standard operating range spans -20°C to +100°C (-4°F to +212°F). However, you can use this cable at lower temperatures under specific conditions. The installation must prevent the cable from flexing or bending. Therefore, static installations may work below -20°C. Flexing the 200151-40-02-10 at temperatures below -20°C may cause cable damage. Consequently, always assess your application's mechanical requirements first.

The connector sealing compound offers additional temperature protection. The DC4 electrical insulating compound withstands -55°C to +121°C (-67°F to +250°F). This compound requires 24 hours of cure time for full effectiveness. Additionally, the compound provides extra moisture protection during thermal shock events. For example, rapid temperature changes will not compromise the seal integrity.

Construction and Build Quality

The 200151-40-02-10 uses a 4-conductor, 22 AWG internal construction. Each conductor carries signals with minimal resistance. A braided shield surrounds the four conductors completely. Additionally, a drain wire runs alongside the braided shield. This combination achieves 85% minimum shield coverage. Consequently, the 200151-40-02-10 offers excellent noise rejection. The PVC outer jacket resists oils, chemicals, and abrasion. Therefore, this cable suits harsh industrial environments.

The connectors are molded directly to the cable body. This molding process eliminates weak points at the connection joints. Furthermore, nickel-plated coupling nuts resist corrosion over time. The enhanced coupling nut design (-10 option) provides superior grip. For example, you can tighten the 200151-40-02-10 by hand without tools. The improved grip reduces the risk of loose connections during operation.

IP67 Sealing and Moisture Protection

The 200151-40-02-10 achieves an IP67 seal rating to transducers. This rating means complete dust protection and temporary water immersion protection. Specifically, the connectors seal effectively against moisture ingress. The molded connector design prevents water from entering the cable interface. Additionally, the DC4 electrical insulating compound adds another protection layer. This compound fills internal spaces within the connector body. Consequently, the 200151-40-02-10 withstands humid and wet environments.

During thermal shock events, moisture can condense inside standard connectors. However, the DC4 compound prevents this condensation from causing damage. Therefore, the 200151-40-02-10 maintains signal integrity during temperature cycling. This feature proves critical in outdoor or unconditioned installations. For instance, power generation facilities often experience rapid temperature changes.

Signal Integrity and Noise Rejection

The 200151-40-02-10 preserves accelerometer signal quality over its 4.0 meter length. The braided shield with drain wire rejects electromagnetic interference effectively. Additionally, the twisted pair configuration within the 4 conductors reduces common mode noise. Consequently, your monitoring system receives clean, accurate vibration data. The 200151-40-02-10 also minimizes signal attenuation over distance. Therefore, you can place monitoring equipment away from measurement points.

The enhanced coupling nuts ensure consistent ground continuity. A poor ground connection often introduces noise into accelerometer signals. However, the -10 coupling nut option provides secure, low-resistance connections. For example, tighten the 200151-40-02-10 firmly to achieve optimal grounding. This attention to detail improves overall system measurement accuracy.

Installation Guide

Follow these steps to install the 200151-40-02-10 correctly.

1. Inspect the Cable: Check for any visible damage before installation.

2. Plan the Route: Avoid sharp corners and high-temperature surfaces.

3. Calculate Bend Radius: Maintain at least 63.5 mm minimum bend radius.

4. Connect to Accelerometer: Screw one end onto the accelerometer firmly.

5. Tighten Coupling Nuts: Use the enhanced grip of the -10 option.

6. Route to Monitor: Run the 200151-40-02-10 to your monitoring device.

7. Connect Second End: Attach the remaining connector to the monitor input.

8. Secure the Cable: Use cable ties at regular intervals along the route.

Important: Do not exceed the minimum bend radius of 63.5 mm. Additionally, avoid flexing the 200151-40-02-10 below -20°C. Allow the DC4 compound to cure for 24 hours before exposing the cable to moisture. Finally, perform a continuity check after installation completes.

Key Features and Benefits

• 4.0 Meter Length: Provides flexible placement of monitoring equipment.

• Enhanced Coupling Nuts: Offers better grip for hand tightening.

• IP67 Sealing: Protects against dust and temporary water immersion.

• Braided Shield: Delivers 85% coverage for noise rejection.

• Wide Temperature Range: Operates from -20°C to +100°C reliably.

• Molded Connectors: Eliminates weak points at cable ends.

The 200151-40-02-10 combines durability with signal integrity. Consequently, this cable is a trusted choice for vibration monitoring systems. Its frequency response remains flat across the accelerometer's operating range. Additionally, the sensitivity of your measurement system improves with proper cabling. The 200151-40-02-10 maintains linearity by avoiding signal distortion. Environmental tolerance includes resistance to oils and humidity.

Package Contents

• One 200151-40-02-10 accelerometer cable (4.0 meters)

• One installation instruction sheet

Frequently Asked Questions (FAQ)

1. Can I use the 200151-40-02-10 with any Bently Nevada accelerometer?

Yes, the 200151-40-02-10 works with all Bently Nevada accelerometers. The connectors are designed for standard Bently Nevada interfaces. However, always verify your accelerometer's connector type before ordering.

2. What happens if I bend the 200151-40-02-10 below its minimum radius?

Bending below 63.5 mm may damage the internal conductors. Signal attenuation or open circuits can result from tight bends. Therefore, always respect the minimum bend radius specification.

3. Is the 200151-40-02-10 suitable for outdoor installations?

Yes, the IP67 rating makes this cable suitable for outdoor use. Additionally, the PVC jacket resists UV exposure reasonably well. However, avoid prolonged direct sunlight exposure for maximum cable life.

4. How do I clean the connectors on the 200151-40-02-10?

Use a dry, lint-free cloth to wipe the connector surfaces. Do not use solvents or abrasive cleaners on the 200151-40-02-10. Solvents may damage the molded connector body or sealing compound.

5. Can the 200151-40-02-10 be extended with a junction box?

Yes, you can extend this cable using a proper junction box. However, use shielded extension cables to maintain noise rejection. The total length affects signal sensitivity and frequency response limits.
