What Is the 1756-IB16?

When precise monitoring of DC signals is critical, the 1756-IB16 provides reliable performance. This Allen-Bradley ControlLogix digital DC input module features 16 input points and operates within a voltage range of 10-31.2 VDC. It is designed for use with 1756-TBNH or 1756-TBSH removable terminal blocks, ensuring secure connections in industrial environments.

Key Features & Technical Specs

• Manufacturer: Rockwell Automation, brand: Allen-Bradley, part number: 1756-IB16.
• Series: ControlLogix, module type: digital DC input module.
• Input voltage: 12-24 Volts DC sink, operating voltage range: 10-31.2 Volts DC.
• Maximum operating current: 10 milliamperes at 31.2 Volts DC; minimum: 2 milliamperes at 10 Volts DC.
• Input delay time: 2 milliseconds plus selected filter time; OFF to ON: 290 µs nom/1 ms max plus filter time.
• Power dissipation: 5.1 W at 60 °C (140 °F); thermal dissipation: 21.1 BTU/hr at 60 °C.
• Backplane current: 2 milliamperes at 24 Volts, 120 milliamperes at 5.1 Volts.

Applications & Use Cases

In discrete manufacturing and process control, the 1756-IB16 excels at monitoring limit switches, push buttons, and sensor outputs. Its 16-point configuration suits medium-density I/O requirements. For example, in a packaging line, this module can track multiple machine states simultaneously. Additionally, its electronic keying prevents incorrect module insertion, reducing commissioning errors.

Installation & Setup

Mount the 1756-IB16 directly into a ControlLogix local or remote chassis. Ensure the chassis and power supply are installed and grounded before insertion. Use a compatible removable terminal block (1756-TBNH or 1756-TBSH) for wiring. The module supports user-configurable filter times of 0, 1, or 2 milliseconds for input delay, allowing adjustment to application needs.

Maintenance & Reliability

To maintain long-term reliability, inspect the module periodically for dust or debris on the terminal block connections. Verify that the backplane current remains within specified limits: 2 milliamperes at 24 Volts and 120 milliamperes at 5.1 Volts. The module's power dissipation of 5.1 W at 60 °C ensures stable operation even in warm cabinets. Regular checks of the electronic keying status help prevent misinstallation.

Compatibility & Integration

The 1756-IB16 integrates seamlessly with ControlLogix processors and chassis. It works with 1756-TBNH and 1756-TBSH removable terminal blocks. For larger systems, it supports remote I/O and distributed control system configurations. Note that communication protocols are not specified in the datasheet; refer to official Allen-Bradley documentation for network compatibility.

FAQs about 1756-IB16

Q: What is the input voltage range of the 1756-IB16?

A: The operating voltage range is 10-31.2 Volts DC, with a nominal input voltage of 12-24 Volts DC sink.

Q: How many input points does the 1756-IB16 have?

A: The module has 16 input points, organized in two groups of eight.

Q: What is the maximum power dissipation of the 1756-IB16?

A: The maximum power dissipation is 5.1 W at 60 °C (140 °F).

Q: Can the 1756-IB16 be used with AC signals?

A: The module is designed for DC signals; for AC inputs, use appropriate interposing circuitry.

Q: What terminal blocks are compatible with the 1756-IB16?

A: Compatible removable terminal blocks include 1756-TBNH and 1756-TBSH.

Product Support & Availability

The 1756-IB16 is available from PetroPartsOnline, an industrial automation supplier. Verify current lifecycle status and stock before ordering. For technical support, consult official Allen-Bradley documentation or contact PetroPartsOnline directly.
