Introduction

PetroPartsOnline reports that the Allen-Bradley 2094-BC04-M03-M Integrated Axis Module is now available for industrial automation professionals. This module belongs to the Kinetix 6000 Multi-axis servo drive family and delivers robust performance for demanding motion control applications. The 2094-BC04-M03-M offers a continuous power output to bus of 27.6kW and a continuous output current to bus of 41.5A, making it a powerful solution for multi-axis systems.

Key Features

The 2094-BC04-M03-M operates with an AC input voltage of 324 to 528V rms, three-phase, with a nominal range of 360 to 480V. This 400V class module supports a bus overvoltage trip at 825V DC and a bus undervoltage trip at 275V DC, ensuring reliable protection. The module also features a control voltage of 95 to 264V rms, single-phase, with a nominal range of 110 to 240V rms, simplifying integration with standard control systems.

Another key feature is the integrated power dissipation range of 94 to 255 Watts, which helps manage thermal performance in enclosed cabinets. The module requires an installation clearance of 50.8 mm (2.0 in.) and a minimum enclosure depth of 272 mm (10.7 in.), allowing for efficient space planning. With dimensions of 7.7 x 11.9 x 16.7 in (196 x 302 x 426 mm) and a weight of 21.0 lbs (9.53 kg), the 2094-BC04-M03-M is designed for straightforward mounting in standard industrial enclosures.

Technical Specifications

The 2094-BC04-M03-M provides a continuous power output to bus of 27.6kW and a continuous output current to bus of 41.5A. Its output current rating is 30 Amperes, and the voltage rating is 460 Volt (AC). The nominal drive voltage range is 360 to 480 Volts (3 Phase), and the wattage is 13 kWatts. These specifications make the module suitable for high-performance servo drives in packaging, material handling, and assembly applications.

The module also includes a max bus capacitance of 8955 Microfarads, which supports stable DC bus operation. The operating temperature range is 32 to 122 F (0 to 50 C), ensuring reliable performance in typical industrial environments. For circuit protection, the module recommends control input fuses FNQ-R-10 (10 A) or FNQ-R-7.5 (7.5 A) and control input breakers 1492-SPM2D060 or 1492-SPM1D150. The DC bus power fuse options include Bussmann Fuse WJ-20A14F or Mersen DCT20-2; HSJ20.

Applications

The 2094-BC04-M03-M is ideal for multi-axis servo drive systems in industries such as packaging, material handling, and assembly lines. In packaging, the module provides precise motion control for high-speed wrapping, labeling, and cartoning machines. In material handling, it powers conveyors, sorters, and robotic pick-and-place systems with reliable torque and speed control. For assembly lines, the module supports synchronized motion for multi-axis robots and automated stations, improving throughput and accuracy.

The module's 400V class design and 27.6kW continuous power make it suitable for applications requiring high power density and compact footprint. Its integrated axis module architecture simplifies wiring and reduces panel space compared to discrete drive solutions. The 2094-BC04-M03-M also supports standard control voltages and protection features, enabling seamless integration into existing Kinetix 6000 systems.

Availability

PetroPartsOnline stocks the Allen-Bradley 2094-BC04-M03-M Integrated Axis Module for immediate shipment. Customers can expect fast delivery and dedicated technical support for integration and commissioning. Contact PetroPartsOnline today for pricing and availability, and leverage our expertise in industrial automation and oil & gas parts to optimize your motion control systems.

Frequently Asked Questions

What is the lead time for the 2094-BC04-M03-M?

PetroPartsOnline maintains inventory of the 2094-BC04-M03-M, allowing for quick order fulfillment. Typical lead time is 1-2 business days for in-stock items, with expedited shipping options available. Contact our sales team for current stock status and delivery estimates.

Does the 2094-BC04-M03-M come with a warranty?

Yes, the Allen-Bradley 2094-BC04-M03-M comes with a standard manufacturer warranty from Rockwell Automation. PetroPartsOnline also offers extended warranty and support options. Please inquire with our team for specific warranty terms and coverage details.

What are the compatible systems for the 2094-BC04-M03-M?

The 2094-BC04-M03-M is designed for the Kinetix 6000 multi-axis servo drive family. It integrates with compatible Allen-Bradley controllers, such as ControlLogix and CompactLogix, via standard communication protocols. The module requires a 3-phase AC input voltage of 324 to 528V rms and a control voltage of 95 to 264V rms. For detailed compatibility and integration guidelines, refer to the product manual or contact PetroPartsOnline technical support.
