Product Summary

The 1762-L24BXB is a compact MicroLogix 1200 controller from Allen-Bradley. It handles micro and small automation tasks with precision and reliability. This unit integrates fourteen inputs and ten outputs for flexible system control.

Product Procurement & Buyer Guide

Core Specifications for Your Application

This controller operates on a 24VDC power supply. It consumes a maximum of 27 Watts for efficient energy use. The built-in supply delivers 400 mA at 5VDC and 350 mA at 24VDC.

Input and Output Configuration Details

The module includes ten standard 24VDC inputs for general sensing. It also features four fast 24VDC inputs for high-speed counting applications. For outputs, it provides five relay and four 24VDC FET channels. A single high-speed 24VDC FET output supports position monitoring tasks.

Communication and Connectivity Options

This PLC uses an 8-pin mini-DIN serial port for programming. It supports DF1, DH-485, ASCII, and MODBUS protocols seamlessly. You can connect it directly to SCADA and HMI visualization systems. This allows for easy hardware configuration and online edits.

Mechanical and Environmental Tolerances

The unit measures 90 mm in height and 160 mm in width. Its depth is 87 mm for a compact panel footprint. It operates reliably in temperatures from 0 to 55 degrees Celsius. You can store it safely in environments from -40 to 85 degrees Celsius.

Mounting and Installation Requirements

This controller supports either DIN rail or direct panel mounting. Always install it inside an industrial enclosure for protection. Keep it away from load lines and AC motor drives. This reduces the effects of electrical interference and environmental exposure.

Logistics & Standard Packaging Details

• • One (1) Allen-Bradley 1762-L24BXB MicroLogix 1200 PLC unit.
  • Product documentation and installation guide.
  • Standard anti-static packaging for safe transport.

• Express delivery shipping is available via FedEx, UPS, and DHL.

Output Circuit Type and Relay Ratings

The output circuit type is both relay and FET for versatile use. Relay contacts handle 24-125VDC and 120-240VAC loads effectively. Each relay supports a minimum load current of 10 mA. The mechanical cycles rating reaches 20,000,000 for long service life.

Power Supply and Inrush Current Handling

The power supply usage for this module is 27 Watts total. It handles an inrush current of 15 Amps for 20 milliseconds. This robust design ensures stable startup in demanding industrial environments. The heat dissipation is 17 Watts during normal operation.

Input Circuit Type and Common Current

The input circuit type is 24 VDC sink or source for flexibility. This module has no sensor power output for external devices. The common current per group is 7.5 Amps for output groups. This ensures reliable power distribution across connected loads.

Operating Frequency for High-Speed Tasks

The operating frequency ranges from 0 to 20 kilohertz for fast inputs. This supports precise counting, totalizing, and position monitoring tasks. The high-speed output matches this frequency for synchronized control loops. This makes the controller ideal for micro automation requirements.
