Introduction to the TSXCANKCDF90TP

When engineers need a reliable connection for CANopen bus systems, the Schneider TSXCANKCDF90TP offers a compact solution. This accessory is part of the TSX series and is designed for CANopen networks. It features a SUB-D9 female connector bended at 90 degrees with an additional SUB-D9 connector, all housed in an IP20-rated enclosure.

Technical Specifications and Performance

The TSXCANKCDF90TP weighs 0.11 lb (US), which is 0.051 kg, making it lightweight for easy installation. Its IP degree of protection is IP20, suitable for indoor use where dust and moisture are controlled. The electrical connection includes one female connector SUB-D 9 elbowed and one male connector SUB-D 9, providing flexibility in wiring configurations.

This connector is categorized as a connection accessory and a connector with line terminator, ensuring proper signal termination on the CANopen bus. The product is manufactured in Germany, as indicated by the country of origin DE.

Applications in Modern Manufacturing

In automated production lines, the TSXCANKCDF90TP connects CANopen devices such as sensors and actuators to the bus backbone. Its 90-degree female connector saves space in tight control cabinets, while the additional male connector allows daisy-chaining to other nodes. This setup is common in packaging, material handling, and assembly systems.

For oil and gas applications, the IP20 rating makes it suitable for clean, dry environments like control rooms or monitoring stations. The connector's robust design supports reliable data transmission in moderate industrial settings.

Customer Case Scenario

A manufacturing plant upgraded its conveyor system with CANopen drives and needed a compact connector for the bus line. By using the TSXCANKCDF90TP, they reduced wiring clutter and ensured proper termination, leading to fewer communication errors. This illustration shows how the connector simplifies network installation.

Compatibility and Integration

The TSXCANKCDF90TP is designed for the CANopen bus type, as specified in the product range. It works with Schneider's TSX series controllers and other CANopen-compatible devices. The connector's dual SUB-D9 ports allow easy integration into existing bus topologies without additional adapters.

Frequently Asked Questions About the TSXCANKCDF90TP

What is the weight of the TSXCANKCDF90TP?

The TSXCANKCDF90TP weighs 0.11 lb (US), which is 0.051 kg, as per the product specifications.

What type of connectors does the TSXCANKCDF90TP have?

It includes one female connector SUB-D 9 elbowed and one male connector SUB-D 9, allowing for angled and straight connections on the CANopen bus.

What is the IP protection rating of this connector?

The TSXCANKCDF90TP has an IP degree of protection of IP20, suitable for indoor industrial environments.

Where is the TSXCANKCDF90TP manufactured?

The country of origin for this product is Germany (DE), as indicated in the ordering and shipping details.

Conclusion and Supply Assurance

PetroPartsOnline offers the Schneider TSXCANKCDF90TP for industrial automation needs. With expertise in supplying automation components, we ensure genuine parts and reliable delivery. Please verify current lifecycle status and availability with PetroPartsOnline before ordering.
