The 0.3m fixed size fits short-range connections inside standard cabinets. Factory pre-assembled dual female SUB-D9 connectors support true plug-and-play use. This design cuts on-site wiring time and avoids poor contact from manual crimping work.

The outer sheath adopts low-smoke zero-halogen material. It delivers flame retardancy and strong anti-aging performance. The IP20 rating blocks dust and foreign matter from touching internal conductors. It runs stably in conventional indoor industrial cabinets all year round.

It fully complies with standard CANopen protocol for full compatibility with Schneider Modicon PLC series. The built-in shielding structure resists strong electromagnetic interference. It maintains complete signal quality near high-power equipment and motors.

Power off all PLC units and slave devices before operation. Plug two cable ends into the CAN ports of controllers and field equipment separately. Fasten the cable with ties and keep a 10cm gap from power lines. Next, install 120Ω terminal resistors at both bus ends, then power on devices and run function tests.

Check cable appearance and connectors every week. Confirm no shell damage or loose connections. Clean dust on connector pins every month to prevent metal oxidation and contact failure.

Do not use this cable outdoors or in humid workshops due to its IP20 rating. Keep it away from high temperature, oil stains and corrosive gas. Inspect shielding grounding every quarter to retain stable anti-interference performance.

Loose connectors, bent pins or missing terminal resistors trigger this fault. Power off the whole system first, then reinsert connectors and straighten deformed pins. Install standard 120Ω resistors and unify the baud rate of all bus devices.

Parallel layout with power cables or damaged shielding leads to unstable communication. Rearrange cable routes to stay away from high-voltage lines. Replace aging cables and recheck single-end shielding grounding status.

Frequent plugging and pulling will damage SUB-D9 pins and plastic housings. Use fine tweezers to fix slightly bent pins on site. Replace the entire cable once connectors crack, because partial replacement will destroy integrated shielding.

Long-term high temperature and oil corrosion wear down the outer sheath. Wrap minor damaged areas with insulating tape for temporary use. Replace the cable promptly to prevent hidden short circuit risks.

It connects Schneider Modicon M221, M340, M580 PLCs and standard CANopen slave modules, drives and servo systems. It only applies to short-distance wiring inside control cabinets.

This is a professional CANopen bus cable with dedicated shielding and impedance matching. Ordinary network cables lack industrial anti-interference design. For this reason, they cannot replace it for industrial CAN bus networking.

Yes. Choose TSXCANCADD1 (1m) or TSXCANCADD3 (3m) for longer wiring demands. Pick flexible versions if the cable needs to move along drag chains in automated equipment.

Replace the cable right away if you find cracked sheaths, broken connectors or recurring communication faults. Also replace cables after five years of continuous operation to avoid unexpected production downtime.

Check clear model markings and complete CE & RoHS certifications on packages. Inspect neat pins and uniform metal shells on SUB-D9 connectors. Reject bulk refurbished products with blurry printing and poor welding quality.
