Product Overview

The Bently Nevada 200151-40-03-10 is a standard accelerometer interface cable. This cable features connectors on both ends for easy installation. The 200151-40-03-10 has a length of exactly 4.0 meters. It includes a blue cable with armor protection for added durability. The enhanced coupling nuts provide a better grip during tightening. This cable connects accelerometers to monitoring systems reliably.

Technical Specifications

The 200151-40-03-10 uses a robust 4-conductor construction. Each conductor is 22 AWG with a braided shield. The shield provides 85% minimum coverage for noise protection. A drain wire improves the grounding performance significantly. The outer jacket uses PVC material for flexibility. Nickel-plated coupling nuts resist corrosion in harsh environments.

Cable Construction Details

• Conductor Count: 4 conductors

• Wire Gauge: 22 AWG

• Shielding: Braided shield with drain wire

• Shield Coverage: 85% minimum

• Outer Jacket: PVC material

• Jacket Color: Blue with armor

• Coupling Nuts: Nickel-plated, both ends

Connector Features

The 200151-40-03-10 has molded connectors on both ends. These connectors provide an IP67 seal to transducers and mating hardware. The sealing prevents dust and water ingress effectively. DC4 electrical insulating compound fills the connector interior. This compound adds protection against moisture during thermal shock. The enhanced coupling nut option (code 10) improves grip strength. Users can tighten the cable to accelerometers without slipping.

Temperature Ratings

• Operating Temperature: -20°C to +100°C (-4°F to +212°F)

• Lower Temperature Note: Avoid flexing below -20°C to prevent damage

• Connector Cure Temperature Range: -55°C to +121°C (-67°F to +250°F)

• Cure Time: 24 hours for full compound setting

Mechanical Specifications

• Minimum Bend Radius: 63.5 mm (2.5 inches)

• Armor Option Code: 03 (Blue cable with armor)

• Coupling Nut Option Code: 10 (Enhanced grip on both ends)

• Length Code: -40 (4.0 meters)

• Model Base: 200151 Series

Installation Guide

Installing the 200151-40-03-10 cable requires careful handling. First, check that your accelerometer has the matching connector type. Align the coupling nut carefully with the sensor thread. Hand-tighten the nut until you feel initial resistance. Then use the enhanced grip nut to tighten firmly. Do not exceed the minimum bend radius of 63.5 mm during routing. Avoid flexing the cable at temperatures below -20°C. Allow 24 hours for the connector compound to cure after thermal exposure.

Package Contents

When you purchase the 200151-40-03-10 cable, you will receive:

• One Bently Nevada 200151-40-03-10 accelerometer cable (4.0 meters)

• Two enhanced coupling nuts (pre-installed on both ends)

• One cable routing instruction sheet

3-5 Common FAQs

1. Can the 200151-40-03-10 cable be cut to a shorter length?
No, cutting the 200151-40-03-10 cable will break the molded connectors. Order a different length code for your specific distance requirements.

2. Is the 200151-40-03-10 cable compatible with all Bently Nevada accelerometers?
Yes, the 200151-40-03-10 works with standard Bently Nevada accelerometers. The connectors use the industry-standard interface for seismic transducers.

3. What does the armor option 03 protect against?
Armor option 03 on the 200151-40-03-10 protects against crushing and abrasion. It also provides extra protection in high-vibration environments.

4. Can I use this cable in continuous flexing applications?
The 200151-40-03-10 is not designed for continuous flexing. Use it in static installations only for best reliability and cable life.

Conclusion

The Bently Nevada 200151-40-03-10 is a high-quality accelerometer cable. Its 4.0 meter length suits most machine monitoring layouts. The blue armor and enhanced nuts provide superior durability. IP67 sealing keeps moisture away from critical connections. Order the 200151-40-03-10 for reliable sensor wiring in your vibration monitoring system.
